Flotation machines are mainly used to separate nonferrous metals such as copper, zinc, lead, nickel, and gold. They can also be used for rough and fine separation of ferrous metals and non-metals.
Application fields:
The machine can be used to separate nonferrous metal, ferrous metal, noble metal, nonmetallic mine, chemical material and recycle mine.
Flotation machine is the abbreviation of flotation concentrator, which refers to the mechanical equipment that completes the flotation process. In the flotation machine, the pulp treated with reagents is stirred and aerated, so that some mineral particles are selectively fixed on the bubbles; the particles float to the surface of the pulp and are scraped off to form foam products, while the rest remain in the pulp to achieve the purpose of separating minerals.
| Model | Effective volume （m³） | Processing capacity (m³/min) | Motor power (kW) | Spindle speed (r/min) | Scraper speed (r/min) | Scraper power (kw) | Battery size (mm) |
| SF-0.37 | 0.37 | 0.2-0.4 | 1.5 | 352 | 25 | 0.55 | 700×700×750 |
| SF-0.7 | 0.7 | 0.3-0.9 | 3 | 400 | 25 | 1.1 | 900×820×950 |
| SF-1.2 | 1.2 | 0.6-1.6 | 5.5 | 330 | 25 | 1.1 | 1100×1100×1100 |
| SF-2.8 | 2.8 | 1.5-3.5 | 11 | 268 | 25 | 1.1 | 1750×1600×1150 |
| SF-4 | 4 | 2.0-4.0 | 15 | 220 | 25 | 1.5 | 1850×2050×1200 |
| SF-8 | 8 | 4.0-8.0 | 30 | 191 | 25 | 1.5 | 2200×2900×1400 |
| SF-10 | 10 | 5.0-10 | 30 | 191 | 25 | 1.5 | 2200×2900×1700 |
| SF-20 | 20 | 5.0-20 | 30X2 | 191 | 25 | 1.5X2 | 2850×3800×2000 |
